Home > Products > Power Supplies - Board Mount > DC DC Converters > CCG152405S

CCG152405S

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CCG152405S with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	CCG152405S
Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER 5V 15W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 3723 pcs
Reference Price (In US Dollars)	1 pcs	100 pcs
Reference Price (In US Dollars)	$9.643	$9.23

Product parameter
Data sheet

Product parameter

Part Number	CCG152405S	Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER 5V 15W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	3723 pcs	Data sheet	CCG15 Series Datasheet
Category	Power Supplies - Board Mount	Voltage - Output 3	-
Voltage - Output 2	-	Voltage - Output 1	5V
Voltage - Isolation	1.5kV	Voltage - Input (Min)	9V
Voltage - Input (Max)	36V	Type	Isolated Module
Size / Dimension	1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)	Series	CCG15
Power (Watts)	15W	Packaging	Tube
Package / Case	6-DIP Module	Other Names	285-2605 CCG15-24-05S
Operating Temperature	-40°C ~ 85°C	Number of Outputs	1
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Remote On/Off, OCP, OVP	Efficiency	87%
Detailed Description	Isolated Module DC DC Converter 1 Output 5V 3A 9V - 36V Input	Current - Output (Max)	3A
Control Features	Enable, Active Low	Applications	ITE (Commercial)
