Home > Products > Filters > Ferrite Cores - Cables and Wiring > ZCAT13D

ZCAT13D

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ZCAT13D with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ZCAT13D
Manufacturer	TDK Corporation
Description	FERRITE CORE 100 OHM HINGED
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 33154 pcs
Reference Price (In US Dollars)	450 pcs
Reference Price (In US Dollars)	$1.126

Product parameter
Data sheet

Product parameter

Part Number	ZCAT13D	Manufacturer	TDK Corporation
Description	FERRITE CORE 100 OHM HINGED	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	33154 pcs	Data sheet	ZCAT Series
Category	Filters	Type	Flat
Series	ZCAT	Ratings	-
Outer Dimension	0.787" W x 0.512" H (20.00mm x 13.00mm)	Mounting Type	Free Hanging
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material	-
Manufacturer Standard Lead Time	10 Weeks	Length	1.339" (34.00mm)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Inner Dimension	0.335" W x 0.197" H (8.50mm x 5.00mm)
Impedance @ Frequency	100 Ohm @ 100MHz ~ 500MHz	Detailed Description	Hinged (Snap On) Free Hanging Ferrite Core 100 Ohm @ 100MHz ~ 500MHz ID 0.335" W x 0.197" H (8.50mm x 5.00mm) OD 0.787" W x 0.512" H (20.00mm x 13.00mm) Length 1.339" (34.00mm)
Design	Hinged (Snap On)
