Home > Products > Inductors, Coils, Chokes > Fixed Inductors > VLF5010ST-2R2M2R0

VLF5010ST-2R2M2R0

VLF5010ST-2R2M2R0

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VLF5010ST-2R2M2R0 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	VLF5010ST-2R2M2R0
Manufacturer	TDK Corporation
Description	FIXED IND 2.2UH 2A 77 MOHM SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 92845 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
Reference Price (In US Dollars)	$0.697	$0.644	$0.451	$0.365

Product parameter
Data sheet

Product parameter

Part Number	VLF5010ST-2R2M2R0	Manufacturer	TDK Corporation
Description	FIXED IND 2.2UH 2A 77 MOHM SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	92845 pcs	Data sheet	VLF5010S Series
Category	Inductors, Coils, Chokes	Type	Wirewound
Tolerance	±20%	Supplier Device Package	-
Size / Dimension	0.189" L x 0.181" W (4.80mm x 4.60mm)	Shielding	Shielded
Series	VLF	Ratings	-
Q @ Freq	-	Packaging	Original-Reel®
Package / Case	Nonstandard	Other Names	445-4226-6
Operating Temperature	-40°C ~ 105°C	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material - Core	Ferrite
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Inductance Frequency - Test	1MHz
Inductance	2.2µH	Height - Seated (Max)	0.039" (1.00mm)
Frequency - Self Resonant	-	Detailed Description	2.2µH Shielded Wirewound Inductor 2A 77 mOhm Max Nonstandard
DC Resistance (DCR)	77 mOhm Max	Current Rating	2A
Current - Saturation	2A
