ANT016008LCD2442MA1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ANT016008LCD2442MA1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ANT016008LCD2442MA1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ANT016008LCD2442MA1 |
|---|---|
| Manufacturer | TDK Corporation |
| Description | RF ANT 2.4GHZ/5.5GHZ CHIP SLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 4000 pcs | 8000 pcs | 12000 pcs | 28000 pcs | |
|---|---|---|---|---|---|
| $0.106 | $0.099 | $0.095 | $0.091 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ANT016008LCD2442MA1 | Manufacturer | TDK Corporation |
|---|---|---|---|
| Description | RF ANT 2.4GHZ/5.5GHZ CHIP SLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 254220 pcs | Data sheet | ANT016008LCD2442MA1 |
| Category | RF/IF and RFID | VSWR | 6.5, 4 |
| Termination | Solder | Series | - |
| Return Loss | - | Packaging | Tape & Reel (TR) |
| Other Names | 445-15175-2 | Number of Bands | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Height (Max) | 0.016" (0.40mm) |
| Gain | 2.27dBi, 5.18dBi | Frequency Range | 2.4GHz ~ 2.485GHz, 5.15GHz ~ 5.85GHz |
| Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) | Frequency (Center/Band) | 2.4GHz, 5.5GHz |
| Features | - | Detailed Description | 2.4GHz, 5.5GHz WLAN Chip RF Antenna 2.4GHz ~ 2.485GHz, 5.15GHz ~ 5.85GHz 2.27dBi, 5.18dBi Solder Surface Mount |
| Applications | WLAN | Antenna Type | Chip |
