Home > Products > Power Supplies - Board Mount > DC DC Converters > SPM1005-ZCB

SPM1005-ZCB

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SPM1005-ZCB with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SPM1005-ZCB
Manufacturer	Sumida Corporation
Description	DC DC CONVERTER 0.6-3.6V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 16009 pcs
Reference Price (In US Dollars)	250 pcs	500 pcs	1250 pcs
Reference Price (In US Dollars)	$1.935	$1.902	$1.869

Product parameter

Product parameter

Part Number	SPM1005-ZCB	Manufacturer	Sumida Corporation
Description	DC DC CONVERTER 0.6-3.6V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	16009 pcs	Data sheet
Category	Power Supplies - Board Mount	Voltage - Output 4	-
Voltage - Output 3	-	Voltage - Output 2	-
Voltage - Output 1	0.6 ~ 3.6 V	Voltage - Input (Min)	2.95V
Voltage - Input (Max)	6V	Type	Non-Isolated PoL Module
Supplier Device Package	56-LGA (11x9.2)	Size / Dimension	0.43" L x 0.36" W x 0.13" H (11.0mm x 9.2mm x 3.2mm)
Series	SPM1005	Packaging	Tape & Reel (TR)
Package / Case	56-BLGA Module	Other Names	308-2380-2
Operating Temperature	-40°C ~ 85°C	Number of Outputs	1
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Manufacturer Standard Lead Time	14 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Efficiency	94.2%	Detailed Description	Non-Isolated PoL Module DC DC Converter 1 Output 0.6 ~ 3.6 V 6A 2.95V - 6V Input
Current - Output (Max)	6A	Applications	ITE (Commercial)
