Home > Products > Inductors, Coils, Chokes > Fixed Inductors > CDEP105NP-1R3MC-50

CDEP105NP-1R3MC-50

CDEP105NP-1R3MC-50

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CDEP105NP-1R3MC-50 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	CDEP105NP-1R3MC-50
Manufacturer	Sumida Corporation
Description	FIXED IND 1.3UH 11.2A 5.3 MOHM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 82630 pcs
Reference Price (In US Dollars)	500 pcs
Reference Price (In US Dollars)	$0.26

Product parameter
Data sheet

Product parameter

Part Number	CDEP105NP-1R3MC-50	Manufacturer	Sumida Corporation
Description	FIXED IND 1.3UH 11.2A 5.3 MOHM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	82630 pcs	Data sheet	CDEP105
Category	Inductors, Coils, Chokes	Type	Wirewound
Tolerance	±20%	Supplier Device Package	-
Size / Dimension	0.394" L x 0.394" W (10.00mm x 10.00mm)	Shielding	Shielded
Series	CDEP105	Ratings	-
Q @ Freq	-	Packaging	Tape & Reel (TR)
Package / Case	Nonstandard	Other Names	308-2273-2 CDEP105NP-1R3MC-50TR CDEP105NP-1R3MC-50TR-ND
Operating Temperature	-40°C ~ 125°C	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material - Core	Ferrite
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Inductance Frequency - Test	100kHz
Inductance	1.3µH	Height - Seated (Max)	0.220" (5.60mm)
Frequency - Self Resonant	-	Detailed Description	1.3µH Shielded Wirewound Inductor 11.2A 5.3 mOhm Max Nonstandard
DC Resistance (DCR)	5.3 mOhm Max	Current Rating	11.2A
Current - Saturation	16.8A
