MPSL-0156-43-DW-1KGH
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MPSL-0156-43-DW-1KGH with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MPSL-0156-43-DW-1KGH with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MPSL-0156-43-DW-1KGH |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | CONN EDGE DUAL FMALE 86POS 0.156 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $3.718 | $3.381 | $3.296 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $3.043 | $2.874 | $2.747 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | MPSL-0156-43-DW-1KGH | Manufacturer | Sullins Connector Solutions |
|---|---|---|---|
| Description | CONN EDGE DUAL FMALE 86POS 0.156 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11237 pcs | Data sheet | MPxx-x156-xx-DW-x(H)xx(Z)x Drawing |
| Category | Connectors, Interconnects | Termination | Solder |
| Series | - | Read Out | Dual |
| Pitch | 0.156" (3.96mm) | Packaging | Tray |
| Other Names | MPSL-0156-43-DW-1KGH-ND S9685 |
Operating Temperature | - |
| Number of Rows | 2 | Number of Positions/Bay/Row | 43 |
| Number of Positions | 86 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Insulation | Polybutylene Terephthalate (PBT) |
| Manufacturer Standard Lead Time | 3 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Gender | Female | Flange Feature | Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia |
| Features | - | Contact Type | Loop Bellows |
| Contact Material | - | Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Finish | Gold | Color | Blue |
| Card Type | Non Specified - Dual Edge | Card Thickness | 0.062" (1.57mm) |
