GRPB112VWVN-RC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy GRPB112VWVN-RC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy GRPB112VWVN-RC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | GRPB112VWVN-RC |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | CONN HEADER .050" 22PS DL PCB AU |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $0.603 | $0.549 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | GRPB112VWVN-RC | Manufacturer | Sullins Connector Solutions |
|---|---|---|---|
| Description | CONN HEADER .050" 22PS DL PCB AU | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 54328 pcs | Data sheet | Male Headers .050" Data SheetGRPBxx2VWVN-RC |
| Category | Connectors, Interconnects | Voltage - DC Spark Over (Nom) | Brass |
| Type Attributes | - | Termination | Solder |
| Style | Board to Board or Cable | Stacking Direction | Male Pin |
| Shrouding | 0.050" (1.27mm) | Shield Termination | Square |
| Series | - | Row Spacing - Mating | Unshrouded |
| RoHS Status | Bulk | Ripple Current - Low Frequency | - |
| Pitch - Connector | - | Overall Contact Length | 0.091" (2.30mm) |
| Other Names | S9015E-11 | Operating Temperature | -40°C ~ 105°C |
| Number of Rows | 2 | Number of Positions | 22 |
| Number of Contacts | Flash | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | All | Manufacturer Standard Lead Time | 4 Weeks |
| Manufacturer Part Number | GRPB112VWVN-RC | Length - Post (Mating) | - |
| Insulation Material | Gold | Insulation Height | 0.248" (6.30mm) |
| Features | - | Expanded Description | 22 Positions Header Connector 0.050" (1.27mm) Through Hole Gold |
| Description | CONN HEADER .050" 22PS DL PCB AU | Current Rating | 1A |
| Current - Max/Contact | - | Contact Length - Post | 0.118" (3.00mm) |
| Contact Length - Mating | 0.050" (1.27mm) | Contact Finish Thickness - Post | Polyamide (PA9T), Nylon 9T |
| Contact Finish Thickness - Mating | Gold | Contact Finish - Post | Flash |
| Contact Finish - Mating | 0.039" (1.00mm) | Connector Type | Header |
| Actual Diameter | - |
