PQ3218-3R3-70-T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PQ3218-3R3-70-T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PQ3218-3R3-70-T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PQ3218-3R3-70-T |
|---|---|
| Manufacturer | Standex-Meder Electronics |
| Description | FIXED IND 3.3UH 70A 1.1 MOHM TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $3.292 | $2.925 | $2.267 | $2.121 | $1.945 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | PQ3218-3R3-70-T | Manufacturer | Standex-Meder Electronics |
|---|---|---|---|
| Description | FIXED IND 3.3UH 70A 1.1 MOHM TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17642 pcs | Data sheet | PQ20,26,32 Series |
| Category | Inductors, Coils, Chokes | Type | Planar |
| Tolerance | - | Supplier Device Package | - |
| Size / Dimension | 1.260" L x 0.886" W (32.00mm x 22.50mm) | Shielding | Unshielded |
| Series | PQ | Ratings | - |
| Q @ Freq | - | Packaging | Bulk |
| Package / Case | Nonstandard | Other Names | 374-1376 8032183370 |
| Operating Temperature | -30°C ~ 125°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 3.3µH | Height - Seated (Max) | 0.728" (18.50mm) |
| Frequency - Self Resonant | - | Detailed Description | 3.3µH Unshielded Planar Inductor 70A 1.1 mOhm Nonstandard |
| DC Resistance (DCR) | 1.1 mOhm | Current Rating | 70A |
| Current - Saturation | 80A |
