PQ2613-1R0-80-G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PQ2613-1R0-80-G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PQ2613-1R0-80-G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PQ2613-1R0-80-G |
|---|---|
| Manufacturer | Standex-Meder Electronics |
| Description | FIXED IND 1UH 80A 1.2 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PQ2613-1R0-80-G | Manufacturer | Standex-Meder Electronics |
|---|---|---|---|
| Description | FIXED IND 1UH 80A 1.2 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4626 pcs | Data sheet | PQ20,26,32 Series |
| Category | Inductors, Coils, Chokes | Type | Planar |
| Tolerance | - | Supplier Device Package | - |
| Size / Dimension | 1.043" L x 0.748" W (26.50mm x 19.00mm) | Shielding | Unshielded |
| Series | PQ | Ratings | - |
| Q @ Freq | - | Packaging | Bulk |
| Package / Case | Nonstandard | Other Names | 374-1375 8026131080 |
| Operating Temperature | -30°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 1µH |
| Height - Seated (Max) | 0.520" (13.20mm) | Frequency - Self Resonant | - |
| Detailed Description | 1µH Unshielded Planar Inductor 80A 1.2 mOhm Nonstandard | DC Resistance (DCR) | 1.2 mOhm |
| Current Rating | 80A | Current - Saturation | 120A |
