ROB-09238
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ROB-09238 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ROB-09238 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ROB-09238 |
|---|---|
| Manufacturer | SparkFun |
| Description | STEPPER MOTOR HYBRID BIPOLAR 12V |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $5.333 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ROB-09238 | Manufacturer | SparkFun |
|---|---|---|---|
| Description | STEPPER MOTOR HYBRID BIPOLAR 12V | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 7340 pcs | Data sheet | SM-42BYG011-25 Drawing |
| Category | Motors, Solenoids, Driver Boards/Modules | Weight | 0.441 lb (200.03g) |
| Voltage - Rated | 12VDC | Type | Hybrid |
| Torque - Holding (oz-in / mNm) | 32.57 / 230 | Termination Style | Wire Leads |
| Steps per Revolution | 200 | Step Angle | 1.8° |
| Size / Dimension | Square - 1.665" x 1.665" (42.30mm x 42.30mm) | Series | - |
| Rotor Inertia | 18.7gcm² | Other Names | 1568-1105 9238 SM-42BYG011-25 |
| Operating Temperature | - | NEMA Frame Size | 17 |
| Mounting Hole Spacing | 1.220" (31.00mm) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 8 Weeks | Length - Shaft and Bearing | 0.945" (24.00mm) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Features | Round Shaft |
| Diameter - Shaft | 0.197" (5.00mm) | Detailed Description | Bipolar Stepper Motor 200 Step 0.33A 12VDC |
| Current Rating | 330mA | Coil Type | Bipolar |
| Coil Resistance | 32.6 Ohms | Approvals | - |
| Accuracy | - |
