PC847X5J000F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PC847X5J000F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PC847X5J000F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PC847X5J000F |
|---|---|
| Manufacturer | Sharp Microelectronics |
| Description | OPTOISOLTR 5KV 4CH TRANS 16-DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PC847X5J000F | Manufacturer | Sharp Microelectronics |
|---|---|---|---|
| Description | OPTOISOLTR 5KV 4CH TRANS 16-DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4369 pcs | Data sheet | PC847XJ0000F Series |
| Category | Isolators | Voltage - Output (Max) | 80V |
| Voltage - Isolation | 5000Vrms | Voltage - Forward (Vf) (Typ) | 1.2V |
| Vce Saturation (Max) | 200mV | Turn On / Turn Off Time (Typ) | - |
| Supplier Device Package | 16-DIP | Series | - |
| Rise / Fall Time (Typ) | 4µs, 3µs | Packaging | Tube |
| Package / Case | 16-DIP | Output Type | Transistor |
| Other Names | 425-2596-5 PC847X5J000F-ND |
Operating Temperature | -30°C ~ 100°C |
| Number of Channels | 4 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | DC | Detailed Description | Optoisolator Transistor Output 5000Vrms 4 Channel 16-DIP |
| Current Transfer Ratio (Min) | 80% @ 5mA | Current Transfer Ratio (Max) | 260% @ 5mA |
| Current - Output / Channel | 50mA | Current - DC Forward (If) (Max) | 50mA |
