PC6N139X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PC6N139X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PC6N139X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PC6N139X |
|---|---|
| Manufacturer | Sharp Microelectronics |
| Description | OPTOISO 2.5KV DARL W/BASE 8-DIP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PC6N139X | Manufacturer | Sharp Microelectronics |
|---|---|---|---|
| Description | OPTOISO 2.5KV DARL W/BASE 8-DIP | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4225 pcs | Data sheet | 6N139 |
| Category | Isolators | Voltage - Output (Max) | 18V |
| Voltage - Isolation | 2500Vrms | Voltage - Forward (Vf) (Typ) | 1.5V |
| Vce Saturation (Max) | - | Turn On / Turn Off Time (Typ) | 300ns, 1.5µs |
| Supplier Device Package | 8-DIP | Series | - |
| Rise / Fall Time (Typ) | - | Packaging | Tube |
| Package / Case | 8-DIP (0.300", 7.62mm) | Output Type | Darlington with Base |
| Other Names | 425-1801-5 | Operating Temperature | 0°C ~ 70°C |
| Number of Channels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Input Type | DC | Detailed Description | Optoisolator Darlington with Base Output 2500Vrms 1 Channel 8-DIP |
| Current Transfer Ratio (Min) | 400% @ 0.5mA | Current Transfer Ratio (Max) | - |
| Current - Output / Channel | 60mA | Current - DC Forward (If) (Max) | 20mA |
