EGUARD0522PTR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EGUARD0522PTR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy EGUARD0522PTR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EGUARD0522PTR |
|---|---|
| Manufacturer | Sensitron Semiconductor / SMC Diode Solutions |
| Description | TVS DIODE 5V 17V 6DFNWB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | 6000 pcs | 15000 pcs | 30000 pcs | |
|---|---|---|---|---|---|
| $0.038 | $0.035 | $0.033 | $0.03 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | EGUARD0522PTR | Manufacturer | Sensitron Semiconductor / SMC Diode Solutions |
|---|---|---|---|
| Description | TVS DIODE 5V 17V 6DFNWB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 748074 pcs | Data sheet | EGUARD0522P |
| Category | Circuit Protection | Voltage - Reverse Standoff (Typ) | 5V (Max) |
| Voltage - Clamping (Max) @ Ipp | 17V | Voltage - Breakdown (Min) | 6V |
| Unidirectional Channels | 2 | Type | Steering (Rail to Rail) |
| Supplier Device Package | 6-DFNWB (1.45x1) | Series | - |
| Power Line Protection | No | Power - Peak Pulse | 150W |
| Packaging | Tape & Reel (TR) | Package / Case | 6-UFDFN |
| Other Names | 1655-1418-2 EGUARD0522P |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Current - Peak Pulse (10/1000µs) | 7A (8/20µs) | Capacitance @ Frequency | 0.65pF @ 1MHz |
| Applications | HDMI |
