RS614-1-02
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RS614-1-02 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RS614-1-02 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RS614-1-02 |
|---|---|
| Manufacturer | Schaffner EMC, Inc. |
| Description | CMC 120UH 1A 2LN TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $2.30 | $2.092 | $1.423 | $1.297 | $1.237 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | RS614-1-02 | Manufacturer | Schaffner EMC, Inc. |
|---|---|---|---|
| Description | CMC 120UH 1A 2LN TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 31755 pcs | Data sheet | RS Series Datasheet |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | 250V | Size / Dimension | 0.906" L x 0.610" W (23.00mm x 15.50mm) |
| Series | RS | Ratings | - |
| Packaging | Tray | Package / Case | Vertical, 4 PC Pin |
| Other Names | 290-148 800427 817-1847 RS614-1-02-ND RS614102 |
Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance @ Frequency | 120µH @ 1kHz | Height (Max) | 0.984" (25.00mm) |
| Filter Type | Signal Line | Features | - |
| Detailed Description | 120µH @ 1kHz 2 Line Common Mode Choke Through Hole 1A (Typ) DCR 200 mOhm (Typ) | DC Resistance (DCR) (Max) | 200 mOhm (Typ) |
| Current Rating (Max) | 1A (Typ) | Approvals | UR, VDE |
