RS512-2-02
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RS512-2-02 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RS512-2-02 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RS512-2-02 |
|---|---|
| Manufacturer | Schaffner EMC, Inc. |
| Description | COMMON MODE CHOKE 13UH 2A 2LN TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $2.175 | $1.977 | $1.344 | $1.225 | $1.168 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | RS512-2-02 | Manufacturer | Schaffner EMC, Inc. |
|---|---|---|---|
| Description | COMMON MODE CHOKE 13UH 2A 2LN TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 26249 pcs | Data sheet | RS Series Datasheet |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | 250V | Size / Dimension | 0.697" L x 0.673" W (17.70mm x 17.10mm) |
| Series | RS | Ratings | - |
| Packaging | Tray | Package / Case | Horizontal, 4 PC Pin |
| Other Names | 290-141 800420 817-1846 RS512-2-02-ND RS512202 |
Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance @ Frequency | 13µH @ 1kHz | Height (Max) | 0.492" (12.50mm) |
| Filter Type | Signal Line | Features | - |
| Detailed Description | 13µH @ 1kHz 2 Line Common Mode Choke Through Hole 2A (Typ) DCR 30 mOhm (Typ) | DC Resistance (DCR) (Max) | 30 mOhm (Typ) |
| Current Rating (Max) | 2A (Typ) | Approvals | UR, VDE |
