IT314
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IT314 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy IT314 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | IT314 |
|---|---|
| Manufacturer | Schaffner EMC, Inc. |
| Description | XFRMR PULSE 3:1:1 DUAL 35MH 1A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.595 | $4.134 | $3.816 | $3.689 | ||
| 100 pcs | 300 pcs | 500 pcs | 1000 pcs | ||
| $3.587 | $3.536 | $3.498 | $3.434 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | IT314 | Manufacturer | Schaffner EMC, Inc. |
|---|---|---|---|
| Description | XFRMR PULSE 3:1:1 DUAL 35MH 1A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9293 pcs | Data sheet | IT Series (Double Winding) |
| Category | Transformers | Weight | 0.88 oz (25.08g) |
| Turns Ratio - Primary:Secondary | 3:1:1 | Transformer Type | Data/Voice Coupling |
| Size / Dimension | 1.004" L x 1.004" W (25.50mm x 25.50mm) | Series | IT |
| Packaging | Tray | Other Names | 22-461 800060 817-2352 IT314-ND |
| Operating Temperature | -25°C ~ 70°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 35mH |
| Height - Seated (Max) | 0.992" (25.20mm) | Energy Time (E.T.) | - |
