109BD24HA2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 109BD24HA2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 109BD24HA2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 109BD24HA2 |
|---|---|
| Manufacturer | Sanyo Denki |
| Description | BLOWER 76X30MM 24VDC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $9.885 | $8.986 | $8.686 | $8.087 | $7.588 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 109BD24HA2 | Manufacturer | Sanyo Denki |
|---|---|---|---|
| Description | BLOWER 76X30MM 24VDC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5166 pcs | Data sheet | Fan Part Number GuideSan Ace B76 76x30mm 9BD Type |
| Category | Fans, Thermal Management | Width | 30.00mm |
| Weight | 0.22 lb (99.79g) | Voltage Range | 20.4 ~ 27.6VDC |
| Voltage - Rated | 24VDC | Termination | 2 Wire Leads |
| Static Pressure | 0.610 in H2O (151.9 Pa) | Size / Dimension | Square/Rounded - 76mm L x 75.5mm H |
| Series | Scirocco Ace 76 | RPM | 3000 RPM |
| Power (Watts) | 4.08W | Other Names | 109BD24HA2-ND 1688-1907 |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) | Noise | 41.5 dB(A) |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material - Frame | Plastic |
| Material - Blade | Plastic | Manufacturer Standard Lead Time | 20 Weeks |
| Lifetime @ Temp. | 40000 Hrs @ 60°C | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Features | - |
| Fan Type | Blower | Current Rating | 0.170A |
| Bearing Type | Ball | Approvals | CSA, TUV, UL |
| Air Flow | 12.7 CFM (0.356m³/min) |
