SSM-118-S-SV
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SSM-118-S-SV with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SSM-118-S-SV with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SSM-118-S-SV |
|---|---|
| Manufacturer | Samtec, Inc. |
| Description | CONN RCPT .100" 18POS SNGL VERT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $2.866 | $2.564 | $2.111 | $1.669 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $1.433 | $1.307 | $1.257 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SSM-118-S-SV | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | CONN RCPT .100" 18POS SNGL VERT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 26338 pcs | Data sheet | SSM Series DrawingSSM Series DatasheetSSM (Single Vertical) Footprint |
| Category | Connectors, Interconnects | Voltage Rating | 405VAC, 572VDC |
| Termination | Solder | Style | Board to Board or Cable |
| Series | SSM | Row Spacing - Mating | - |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Bulk |
| Other Names | SAM1152-18 | Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 18 | Mounting Type | Surface Mount |
| Material Flammability Rating | - | Mated Stacking Heights | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Liquid Crystal Polymer (LCP) |
| Insulation Height | 0.290" (7.37mm) | Insulation Color | Black |
| Ingress Protection | - | Features | - |
| Fastening Type | Push-Pull | Detailed Description | 18 Position Receptacle, Pass Through Connector 0.100" (2.54mm) Surface Mount Gold |
| Current Rating | 5.2A per Contact | Contact Type | Female Socket |
| Contact Shape | Square | Contact Material | Phosphor Bronze |
| Contact Length - Post | - | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold | Connector Type | Receptacle, Pass Through |
| Applications | - |
