SMM-104-02-S-D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMM-104-02-S-D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SMM-104-02-S-D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SMM-104-02-S-D |
|---|---|
| Manufacturer | Samtec, Inc. |
| Description | CONN RCPT 2MM 8POS DL GOLD SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $2.344 | $2.03 | $1.718 | $1.367 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $1.113 | $1.015 | $0.976 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SMM-104-02-S-D | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | CONN RCPT 2MM 8POS DL GOLD SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 32880 pcs | Data sheet | SMM-1yy-yy-yy-D-yy-y-yy-yy DrawingSMM Double Row SMT FootprintSMM Series Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 350VAC |
| Termination | Solder | Style | Board to Board or Cable |
| Series | Tiger Eye™ SMM | Row Spacing - Mating | 0.079" (2.00mm) |
| Pitch - Mating | 0.079" (2.00mm) | Packaging | Bulk |
| Other Names | SAM1243-04 | Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 8 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.140" (3.56mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 8 Position Receptacle Connector 0.079" (2.00mm) Surface Mount Gold | Current Rating | 3.2A per Contact |
| Contact Type | Female Socket | Contact Shape | Square |
| Contact Material | Beryllium Copper | Contact Length - Post | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | - |
