SMM-101-02-S-S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMM-101-02-S-S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SMM-101-02-S-S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SMM-101-02-S-S |
|---|---|
| Manufacturer | Samtec, Inc. |
| Description | CONN RCPT 2MM 1POS SGL GOLD SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $0.982 | $0.85 | $0.719 | $0.572 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $0.466 | $0.425 | $0.409 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SMM-101-02-S-S | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | CONN RCPT 2MM 1POS SGL GOLD SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 81371 pcs | Data sheet | SMM Single Row SMT FootprintSMM-1yy-yy-yy-D-yy-y-yy-yy DrawingSMM Single Row DrawingSMM Series Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 350VAC |
| Termination | Solder | Style | Board to Board or Cable |
| Series | Tiger Eye™ SMM | Row Spacing - Mating | - |
| Pitch - Mating | - | Packaging | Bulk |
| Other Names | SAM1244-01 | Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 1 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.140" (3.56mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 1 Position Receptacle Connector Surface Mount | Current Rating | 3.2A per Contact |
| Contact Type | Female Socket | Contact Shape | Square |
| Contact Material | Beryllium Copper | Contact Length - Post | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | - |
