SFM-110-01-L-D-A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SFM-110-01-L-D-A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SFM-110-01-L-D-A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SFM-110-01-L-D-A |
|---|---|
| Manufacturer | Samtec, Inc. |
| Description | .050" X .050 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 35 pcs | 105 pcs | 525 pcs | 1015 pcs |
|---|---|---|---|---|---|
| $1.703 | $1.377 | $1.115 | $0.918 | $0.852 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | SFM-110-01-L-D-A | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | .050" X .050 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 37201 pcs | Data sheet | SFM(x)/SFC Thru Hole Footprint (Double)SFM(L) Series DatasheetSFM Series Drawing, Double Row |
| Category | Connectors, Interconnects | Voltage Rating | 250VAC |
| Termination | Solder | Style | Board to Board or Cable |
| Series | Tiger Eye™ SFM | Row Spacing - Mating | 0.050" (1.27mm) |
| Pitch - Mating | 0.050" (1.27mm) | Packaging | Tube |
| Other Names | SAM9123 SFM-110-01-L-D-A-ND |
Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 20 | Mounting Type | Through Hole |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | 6.02mm, 6.17mm, 7.80mm, 7.95mm, 9.58mm, 9.73mm, 11.48mm, 11.63mm |
| Manufacturer Standard Lead Time | 3 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.180" (4.57mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | Board Guide | Fastening Type | Push-Pull |
| Detailed Description | 20 Position Receptacle Connector Through Hole | Current Rating | 3.2A per Contact |
| Contact Type | Female Socket | Contact Shape | Square |
| Contact Material | Beryllium Copper | Contact Length - Post | 0.120" (3.05mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | 10.0µin (0.25µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | - |
