SDL-136-TT-10
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SDL-136-TT-10 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SDL-136-TT-10 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SDL-136-TT-10 |
|---|---|
| Manufacturer | Samtec, Inc. |
| Description | CONN RCPT .100" 72POS DUAL TIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $2.242 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SDL-136-TT-10 | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | CONN RCPT .100" 72POS DUAL TIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 16838 pcs | Data sheet | SL, SDL DatasheetSD(L), SL, SS, HSS Series Drawing 2SD(L), SL, SS, HSS Series Drawing 1 |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Board |
| Series | SDL | Row Spacing - Mating | 0.100" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Tube |
| Other Names | SAM1139-36 | Operating Temperature | -55°C ~ 105°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 72 | Mounting Type | Through Hole |
| Material Flammability Rating | - | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 3 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.122" (3.10mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 72 Position Receptacle Connector 0.100" (2.54mm) Through Hole Tin | Current Rating | - |
| Contact Type | Female Socket | Contact Shape | Circular |
| Contact Material | Beryllium Copper | Contact Length - Post | 0.108" (2.75mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
| Connector Type | Receptacle | Applications | - |
