QSH-060-01-L-D-A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy QSH-060-01-L-D-A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy QSH-060-01-L-D-A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | QSH-060-01-L-D-A |
|---|---|
| Manufacturer | Samtec, Inc. |
| Description | CONN RCPT HI-SPD .5MM 120POS DL |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 64 pcs | |
|---|---|---|---|---|---|
| $3.325 | $3.129 | $3.041 | $2.836 | ||
| 128 pcs | 256 pcs | 512 pcs | 1024 pcs | ||
| $2.738 | $2.543 | $2.494 | $2.396 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | QSH-060-01-L-D-A | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | CONN RCPT HI-SPD .5MM 120POS DL | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 16492 pcs | Data sheet | QSH Series DatasheetQSH-yyy-01-y-D-yyy DrawingQSH-yyy-01-y-D-yyy Footprint |
| Category | Connectors, Interconnects | Series | Q Strip® QSH |
| Pitch | 0.020" (0.50mm) | Packaging | Tray |
| Other Names | QSH06001LDA SAM8181 |
Number of Rows | 2 |
| Number of Positions | 120 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mated Stacking Heights | 5mm, 8mm, 11mm, 14mm, 16mm, 19mm, 25mm |
| Manufacturer Standard Lead Time | 3 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Above Board | 0.128" (3.25mm) | Features | Board Guide, Ground Bus (Plane) |
| Detailed Description | 120 Position Connector Receptacle, Center Strip Contacts Surface Mount Gold | Contact Finish Thickness | 10.0µin (0.25µm) |
| Contact Finish | Gold | Connector Type | Receptacle, Center Strip Contacts |
