Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Arrays > STTH2003CGY-TR

STTH2003CGY-TR

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STTH2003CGY-TR with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	STTH2003CGY-TR
Manufacturer	STMicroelectronics
Description	DIODE ARRAY GP 300V 10A D2PAK
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 75021 pcs
Reference Price (In US Dollars)	1000 pcs
Reference Price (In US Dollars)	$0.51

Product parameter
Data sheet

Product parameter

Part Number	STTH2003CGY-TR	Manufacturer	STMicroelectronics
Description	DIODE ARRAY GP 300V 10A D2PAK	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	75021 pcs	Data sheet	STTH2003C-Y
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	1.25V @ 10A
Voltage - DC Reverse (Vr) (Max)	300V	Supplier Device Package	D²PAK
Speed	Fast Recovery = 200mA (Io)	Series	-
Reverse Recovery Time (trr)	40ns	Packaging	Tape & Reel (TR)
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB	Other Names	497-13434-2 STTH2003CGYTR
Operating Temperature - Junction	-40°C ~ 175°C	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	29 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Diode Type	Standard
Diode Configuration	1 Pair Common Cathode	Detailed Description	Diode Array 1 Pair Common Cathode Standard 300V 10A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Current - Reverse Leakage @ Vr	20µA @ 300V	Current - Average Rectified (Io) (per Diode)	10A
Base Part Number	STTH2003C
