Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Arrays > STPS40SM120CTN

STPS40SM120CTN

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STPS40SM120CTN with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	STPS40SM120CTN
Manufacturer	STMicroelectronics
Description	DIODE ARRAY SCHOTTKY 120V TO220
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 55848 pcs
Reference Price (In US Dollars)	1 pcs	50 pcs	100 pcs	500 pcs	1000 pcs
Reference Price (In US Dollars)	$1.085	$0.921	$0.798	$0.68	$0.573

Product parameter
Data sheet

Product parameter

Part Number	STPS40SM120CTN	Manufacturer	STMicroelectronics
Description	DIODE ARRAY SCHOTTKY 120V TO220	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	55848 pcs	Data sheet	STPS40SM120C
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	830mV @ 20A
Voltage - DC Reverse (Vr) (Max)	120V	Supplier Device Package	TO-220AB Narrow Leads
Speed	Fast Recovery = 200mA (Io)	Series	-
Packaging	Tube	Package / Case	TO-220-3
Other Names	497-15153-5 STPS40SM120CTN-ND	Operating Temperature - Junction	150°C (Max)
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Diode Type	Schottky
Diode Configuration	1 Pair Common Cathode	Detailed Description	Diode Array 1 Pair Common Cathode Schottky 120V 20A Through Hole TO-220-3
Current - Reverse Leakage @ Vr	275µA @ 120V	Current - Average Rectified (Io) (per Diode)	20A
