STL7N60M2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STL7N60M2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy STL7N60M2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | STL7N60M2 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | MOSFET N-CH 600V 5A POWERFLAT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.256 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | STL7N60M2 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | MOSFET N-CH 600V 5A POWERFLAT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 89442 pcs | Data sheet | STL7N60M2 Datasheet |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±25V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | PowerFLAT™ (5x5) | Series | MDmesh™ |
| Rds On (Max) @ Id, Vgs | 1.05 Ohm @ 2A, 10V | Power Dissipation (Max) | 4W (Ta), 67W (Tc) |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerVDFN |
| Other Names | 497-16519-2 STL7N60M2-ND |
Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 42 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 271pF @ 100V | Gate Charge (Qg) (Max) @ Vgs | 8.8nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Drain to Source Voltage (Vdss) | 600V |
| Detailed Description | N-Channel 600V 5A (Tc) 4W (Ta), 67W (Tc) Surface Mount PowerFLAT™ (5x5) | Current - Continuous Drain (Id) @ 25°C | 5A (Tc) |
