STH6N95K5-2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STH6N95K5-2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy STH6N95K5-2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | STH6N95K5-2 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | MOSFET N-CH 950V 6A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $0.47 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | STH6N95K5-2 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | MOSFET N-CH 950V 6A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 79288 pcs | Data sheet | STH6N95K5-2 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 5V @ 100µA |
| Vgs (Max) | ±30V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | H2Pak-2 | Series | MDmesh™ K5 |
| Rds On (Max) @ Id, Vgs | 1.25 Ohm @ 3A, 10V | Power Dissipation (Max) | 110W (Tc) |
| Packaging | Tape & Reel (TR) | Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| Other Names | 497-16316-2 | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 42 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 450pF @ 100V | Gate Charge (Qg) (Max) @ Vgs | 13nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Drain to Source Voltage (Vdss) | 950V |
| Detailed Description | N-Channel 950V 6A (Tc) 110W (Tc) Surface Mount H2Pak-2 | Current - Continuous Drain (Id) @ 25°C | 6A (Tc) |
