STFI9N60M2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STFI9N60M2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy STFI9N60M2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | STFI9N60M2 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | MOSFET N-CH 600V 5.5A TO-220FP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1500 pcs | ||||
|---|---|---|---|---|---|
| $0.313 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | STFI9N60M2 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | MOSFET N-CH 600V 5.5A TO-220FP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 66789 pcs | Data sheet | STF9N60M2 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±25V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | I2PAKFP (TO-281) | Series | MDmesh™ II Plus |
| Rds On (Max) @ Id, Vgs | 780 mOhm @ 3A, 10V | Power Dissipation (Max) | 20W (Tc) |
| Packaging | Tube | Package / Case | TO-251-3 Short Leads, IPak, TO-251AA |
| Operating Temperature | 150°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 42 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 320pF @ 100V |
| Gate Charge (Qg) (Max) @ Vgs | 10nC @ 10V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Drain to Source Voltage (Vdss) | 600V | Detailed Description | N-Channel 600V 5.5A (Tc) 20W (Tc) Through Hole I2PAKFP (TO-281) |
| Current - Continuous Drain (Id) @ 25°C | 5.5A (Tc) |
