STEVAL-ISA015V2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STEVAL-ISA015V2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy STEVAL-ISA015V2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | STEVAL-ISA015V2 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | BOARD EVAL 3PHASE W/ESBT 100W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | STEVAL-ISA015V2 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | BOARD EVAL 3PHASE W/ESBT 100W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4041 pcs | Data sheet | L6565STEVAL-ISA015V2 Data BriefSTC04IE170HV |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 24V |
| Voltage - Input | 320 ~ 480 VAC | Utilized IC / Part | L6565, STC04IE170HV |
| Supplied Contents | Board(s) | Series | - |
| Regulator Topology | Flyback | Power - Output | 100W |
| Outputs and Type | 1, Isolated | Other Names | 497-5679 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | AC/DC, Primary Side |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Switching | 50 ~ 85kHz |
| Detailed Description | L6565, STC04IE170HV - AC/DC, Primary Side 1, Isolated Outputs Evaluation Board | Current - Output | 4.3A |
| Board Type | Fully Populated |
