LD59030DTPU25R
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LD59030DTPU25R with confidence from Components-World.HK, 1 Year Warranty
Dowload LD59030DTPU25R Details in PDFSee Product Specifications for product details.
Buy LD59030DTPU25R with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LD59030DTPU25R |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IC REG LINEAR 2.5V 300MA 4DFN |
| Lead Free Status / RoHS Status |
| Reference Price (In US Dollars) | 5000 pcs | 10000 pcs | 25000 pcs | 50000 pcs | |
|---|---|---|---|---|---|
| $0.069 | $0.065 | $0.061 | $0.06 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | LD59030DTPU25R | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | IC REG LINEAR 2.5V 300MA 4DFN | Lead Free Status / RoHS Status | |
| Quantity Available | 391473 pcs | Data sheet | Power Mgmt Guide BrochureLD59030 Datasheet |
| Category | Integrated Circuits (ICs) | Voltage Dropout (Max) | 0.23V @ 300mA |
| Voltage - Output (Min/Fixed) | 2.5V | Voltage - Output (Max) | - |
| Voltage - Input (Max) | 5.5V | Supplier Device Package | 4-DFN (1x1) |
| Series | - | Protection Features | Over Temperature |
| Packaging | Tape & Reel (TR) | Package / Case | 4-XDFN Exposed Pad |
| PSRR | 75dB ~ 55dB (1kHz ~ 100kHz) | Output Type | Fixed |
| Output Configuration | Positive | Other Names | 497-17715-2 |
| Operating Temperature | -40°C ~ 125°C | Number of Regulators | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 38 Weeks | Detailed Description | Linear Voltage Regulator IC 1 Output 300mA 4-DFN (1x1) |
| Current - Supply (Max) | 305µA | Current - Quiescent (Iq) | 40µA |
| Current - Output | 300mA | Control Features | Enable, Soft Start |
