Home > Products > RF/IF and RFID > Balun > BAL-CC1101-01D3

BAL-CC1101-01D3

BAL-CC1101-01D3

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BAL-CC1101-01D3 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	BAL-CC1101-01D3
Manufacturer	STMicroelectronics
Description	BALUN 779MHZ-928MHZ 50/50 4WFBGA
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 243962 pcs
Reference Price (In US Dollars)	5000 pcs	10000 pcs	25000 pcs
Reference Price (In US Dollars)	$0.093	$0.089	$0.086

Product parameter
Data sheet

Product parameter

Part Number	BAL-CC1101-01D3	Manufacturer	STMicroelectronics
Description	BALUN 779MHZ-928MHZ 50/50 4WFBGA	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	243962 pcs	Data sheet	BAL-CC1101-01D3
Category	RF/IF and RFID	Series	-
Return Loss (Min)	-15dB	Phase Difference	10°
Packaging	Tape & Reel (TR)	Package / Case	4-WFBGA, FCBGA
Other Names	497-14994-2	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	7 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insertion Loss (Max)	1.9dB
Impedance - Unbalanced/Balanced	50 / 50 Ohm	Frequency Range	779MHz ~ 928MHz
Detailed Description	RF Balun 779MHz ~ 928MHz 50 / 50 Ohm 4-WFBGA, FCBGA
