A2P75S12M3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy A2P75S12M3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy A2P75S12M3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | A2P75S12M3 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IGBT TRENCH 1200V 75A ACEPACK2 |
| Lead Free Status / RoHS Status |
| Reference Price (In US Dollars) | 1 pcs | 14 pcs | |||
|---|---|---|---|---|---|
| $22.453 | $21.093 | ||||
- Product parameter
Product parameter
| Part Number | A2P75S12M3 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | IGBT TRENCH 1200V 75A ACEPACK2 | Lead Free Status / RoHS Status | |
| Quantity Available | 1805 pcs | Data sheet | |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 75A | Supplier Device Package | ACEPACK™ 2 |
| Series | - | Power - Max | 454.5W |
| Package / Case | Module | Other Names | 497-17744 |
| Operating Temperature | -40°C ~ 150°C (TJ) | NTC Thermistor | Yes |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Input Capacitance (Cies) @ Vce | 4700pF @ 25V | Input | Standard |
| IGBT Type | Trench Field Stop | Detailed Description | IGBT Module Trench Field Stop Three Phase Inverter 1200V 75A 454.5W Chassis Mount ACEPACK™ 2 |
| Current - Collector Cutoff (Max) | 100µA | Current - Collector (Ic) (Max) | 75A |
| Configuration | Three Phase Inverter |
