A1P35S12M3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy A1P35S12M3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy A1P35S12M3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | A1P35S12M3 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IGBT TRENCH 1200V 35A ACEPACK1 |
| Lead Free Status / RoHS Status |
| Reference Price (In US Dollars) | 1 pcs | 22 pcs | 110 pcs | ||
|---|---|---|---|---|---|
| $15.004 | $13.999 | $12.155 | |||
- Product parameter
Product parameter
| Part Number | A1P35S12M3 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | IGBT TRENCH 1200V 35A ACEPACK1 | Lead Free Status / RoHS Status | |
| Quantity Available | 3257 pcs | Data sheet | |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Vce(on) (Max) @ Vge, Ic | 2.45V @ 15V, 35A | Supplier Device Package | ACEPACK™ 1 |
| Series | - | Power - Max | 250W |
| Package / Case | Module | Other Names | 497-17740 |
| Operating Temperature | -40°C ~ 150°C (TJ) | NTC Thermistor | Yes |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Input Capacitance (Cies) @ Vce | 2154pF @ 25V | Input | Standard |
| IGBT Type | Trench Field Stop | Detailed Description | IGBT Module Trench Field Stop Three Phase Inverter 1200V 35A 250W Chassis Mount ACEPACK™ 1 |
| Current - Collector Cutoff (Max) | 100µA | Current - Collector (Ic) (Max) | 35A |
| Configuration | Three Phase Inverter |
