Home > Products > Power Supplies - Board Mount > DC DC Converters > RP12-4805DAW/SMD

RP12-4805DAW/SMD

RP12-4805DAW/SMD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RP12-4805DAW/SMD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	RP12-4805DAW/SMD
Manufacturer	RECOM Power
Description	DC DC CONVERTER +/-5V 12W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1616 pcs
Reference Price (In US Dollars)	7 pcs
Reference Price (In US Dollars)	$19.80

Product parameter
Data sheet

Product parameter

Part Number	RP12-4805DAW/SMD	Manufacturer	RECOM Power
Description	DC DC CONVERTER +/-5V 12W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1616 pcs	Data sheet	RP12-AW Series Datasheet
Category	Power Supplies - Board Mount	Voltage - Output 3	-
Voltage - Output 2	-5V	Voltage - Output 1	5V
Voltage - Isolation	1.6kV	Voltage - Input (Min)	18V
Voltage - Input (Max)	75V	Type	Isolated Module
Size / Dimension	1.26" L x 0.80" W x 0.44" H (32.0mm x 20.3mm x 11.2mm)	Series	POWERLINE RP12-AW
Power (Watts)	12W	Packaging	Tube
Package / Case	24-SMD Module, 18 Leads	Other Names	30001437 RP124805DAW/SMD
Operating Temperature	-40°C ~ 61°C	Number of Outputs	2
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	14 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Remote On/Off, OCP, OVP, SCP	Efficiency	85%
Detailed Description	Isolated Module DC DC Converter 2 Output 5V -5V 1.2A, 1.2A 18V - 75V Input	Current - Output (Max)	1.2A, 1.2A
Control Features	Enable, Active High	Applications	ITE (Commercial)
