W3796
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy W3796 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy W3796 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | W3796 |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | RF ANT 829MHZ/1.575GHZ FLAT BAR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $1.567 | $1.399 | $1.259 | |||
| 100 pcs | 250 pcs | 500 pcs | |||
| $1.147 | $1.035 | $0.929 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | W3796 | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | RF ANT 829MHZ/1.575GHZ FLAT BAR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40513 pcs | Data sheet | Antennas SourceBook® Ver 13W3796 Datasheet |
| Category | RF/IF and RFID | VSWR | 3 |
| Termination | Solder | Series | Domino |
| Return Loss | -6dB | Power - Max | 5W |
| Packaging | Cut Tape (CT) | Other Names | 553-3657-1 |
| Number of Bands | 4 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.118" (3.00mm) | Gain | 1.5dBi, 2dBi, 5.5dBi, 5dBi |
| Frequency Range | 698MHz ~ 960MHz, 1.43GHz ~ 1.66GHz, 1.69GHz ~ 2.2GHz, 2.3GHz ~ 2.7GHz | Frequency Group | Wide Band |
| Frequency (Center/Band) | 829MHz, 1.575GHz, 1.9GHz, 2.5GHz | Features | - |
| Detailed Description | 829MHz, 1.575GHz, 1.9GHz, 2.5GHz GPS, LTE Flat Bar RF Antenna 698MHz ~ 960MHz, 1.43GHz ~ 1.66GHz, 1.69GHz ~ 2.2GHz, 2.3GHz ~ 2.7GHz 1.5dBi, 2dBi, 5.5dBi, 5dBi Solder Surface Mount | Applications | GPS, LTE |
| Antenna Type | Flat Bar |
