W3216
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy W3216 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy W3216 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | W3216 |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | RF ANT 1.575/1.602GHZ CER PATCH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | 300 pcs |
|---|---|---|---|---|---|
| $1.108 | $0.99 | $0.891 | $0.812 | $0.733 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $0.658 | $0.555 | $0.527 | $0.507 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | W3216 | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | RF ANT 1.575/1.602GHZ CER PATCH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 77020 pcs | Data sheet | Antennas SourceBook® Ver 13W3216 |
| Category | RF/IF and RFID | VSWR | 1.4, 2.3 |
| Termination | Pin | Series | - |
| Return Loss | - | Packaging | Tray |
| Other Names | 553-2584 W3216-ND |
Number of Bands | 2 |
| Mounting Type | Adhesive | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 5 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Height (Max) | 0.218" (5.53mm) |
| Gain | -2dBi | Frequency Range | 1.575GHz, 1.598GHz ~ 1.606GHz |
| Frequency Group | UHF (1 GHz ~ 2 GHz) | Frequency (Center/Band) | 1.575GHz, 1.602GHz |
| Features | - | Detailed Description | 1.575GHz, 1.602GHz GLONASS, GPS Ceramic Patch RF Antenna 1.575GHz, 1.598GHz ~ 1.606GHz -2dBi Pin Adhesive |
| Applications | GLONASS, GPS | Antenna Type | Ceramic Patch |
