TX1315NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TX1315NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TX1315NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TX1315NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | TRANSFORMER 1CT:1CT 1.2MH SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 70 pcs | |
|---|---|---|---|---|---|
| $1.642 | $1.332 | $1.077 | $1.009 | ||
| 140 pcs | 280 pcs | 560 pcs | 1050 pcs | ||
| $0.963 | $0.935 | $0.907 | $0.878 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TX1315NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | TRANSFORMER 1CT:1CT 1.2MH SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40033 pcs | Data sheet | TX1314/15NL |
| Category | Transformers | Weight | 0.02 oz (0.57g) |
| Turns Ratio - Primary:Secondary | 1CT:1CT | Transformer Type | T1/E1 (Single) |
| Size / Dimension | 0.300" L x 0.276" W (7.62mm x 7.00mm) | Series | - |
| Packaging | Tube | Other Names | 553-1669-5 TX1315NL-ND |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 1.2mH |
| Height - Seated (Max) | 0.250" (6.35mm) | Energy Time (E.T.) | - |
