TX1099NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TX1099NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TX1099NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TX1099NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | XFRMR 1CT:1:0.8/1CT:1:0.8 SMD |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 40 pcs | 80 pcs | |
|---|---|---|---|---|---|
| $1.83 | $1.482 | $1.198 | $1.123 | ||
| 120 pcs | 280 pcs | 520 pcs | 1000 pcs | ||
| $1.072 | $1.041 | $1.009 | $0.978 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TX1099NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | XFRMR 1CT:1:0.8/1CT:1:0.8 SMD | Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Quantity Available | 32653 pcs | Data sheet | T1, Cept, ISDN-PRI Transformers |
| Category | Transformers | Weight | 0.04 oz (1.14g) |
| Turns Ratio - Primary:Secondary | 1CT:1:0.8, 1CT:1:0.8 | Transformer Type | T1/E1 (Dual) |
| Size / Dimension | 0.505" L x 0.280" W (12.83mm x 7.11mm) | Series | - |
| Packaging | Tube | Other Names | 553-1920-5 TX1099NL-ND |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant | Inductance | 1.2mH, 1.2mH |
| Height - Seated (Max) | 0.245" (6.22mm) | Energy Time (E.T.) | - |
