TM8116NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TM8116NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TM8116NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TM8116NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | CMC 470UH 700MA 2LN 800 OHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 75 pcs | 150 pcs | ||
|---|---|---|---|---|---|
| $1.11 | $0.801 | $0.716 | |||
| 525 pcs | 1050 pcs | 2550 pcs | |||
| $0.579 | $0.528 | $0.511 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | TM8116NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | CMC 470UH 700MA 2LN 800 OHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 63020 pcs | Data sheet | TM8116NL Datasheet |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | - | Size / Dimension | 0.260" L x 0.248" W (6.60mm x 6.30mm) |
| Series | - | Ratings | - |
| Packaging | Tube | Package / Case | Horizontal, 4 PC Pad |
| Other Names | 553-3325 553-3325-5 |
Operating Temperature | -40°C ~ 85°C |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance @ Frequency | 470µH @ 100kHz |
| Impedance @ Frequency | 800 Ohms @ 100MHz | Height (Max) | 0.161" (4.10mm) |
| Filter Type | Signal Line | Features | - |
| Detailed Description | 470µH @ 100kHz 2 Line Common Mode Choke Surface Mount 800 Ohms @ 100MHz 700mA DCR 300 mOhm | DC Resistance (DCR) (Max) | 300 mOhm |
| Current Rating (Max) | 700mA | Approvals | - |
