T8005NLT
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy T8005NLT with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy T8005NLT with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | T8005NLT |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | COMMON MODE CHOKE 4.7MH 4LN SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | T8005NLT | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | COMMON MODE CHOKE 4.7MH 4LN SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5054 pcs | Data sheet | T8005, T8006 |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | - | Size / Dimension | 0.360" L x 0.340" W (9.14mm x 8.64mm) |
| Series | - | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | Vertical, 8 Flat Lead |
| Operating Temperature | -40°C ~ 85°C | Number of Lines | 4 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance @ Frequency | 4.7mH @ 100kHz |
| Height (Max) | 0.310" (7.87mm) | Filter Type | Signal Line |
| Features | - | Detailed Description | 4.7mH @ 100kHz 4 Line Common Mode Choke Surface Mount DCR 1.4 Ohm |
| DC Resistance (DCR) (Max) | 1.4 Ohm | Current Rating (Max) | - |
| Approvals | - |
