Home > Products > Transformers > Switching Converter, SMPS Transformers > PH9363NLT

PH9363NLT

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PH9363NLT with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PH9363NLT
Manufacturer	Pulse Electronics Corporation
Description	XFRMER FLYBACK DC/DC CONV SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	100 pcs	250 pcs
~~In Stock~~ 35927 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs
	$1.743	$1.412	$1.142
	$1.07	$1.022	$0.992

Product parameter
Data sheet

Product parameter

Part Number	PH9363NLT	Manufacturer	Pulse Electronics Corporation
Description	XFRMER FLYBACK DC/DC CONV SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	35927 pcs	Data sheet	PH9363, 9496, 0416NL Series
Category	Transformers	Voltage - Primary	8 ~ 18V
Voltage - Isolation	2500Vrms	Voltage - Auxiliary	-
Type	For DC/DC Converters	Size / Dimension	0.472" L x 0.366" W (12.00mm x 9.30mm)
Series	-	Packaging	Cut Tape (CT)
Other Names	553-3662-1	Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	11 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Intended Chipset	ACPL-32JT, ACPL-302J	Inductance @ Frequency	-
Height - Seated (Max)	0.266" (6.75mm)	Frequency	80kHz
Footprint	0.472" L x 0.512" W (12.00mm x 13.00mm)	Chipset Manufacturer	-
Applications	Flyback Converters
