PE-53820NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PE-53820NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PE-53820NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PE-53820NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | FIXED IND 115UH 670MA 400 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.121 | $1.035 | $0.949 | $0.811 | $0.725 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.621 | $0.587 | $0.535 | $0.50 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PE-53820NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | FIXED IND 115UH 670MA 400 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 65618 pcs | Data sheet | THT/SMT Power Inductors - Toroid, Simple Switcher |
| Category | Inductors, Coils, Chokes | Voltage - Breakdown | - |
| Usage | Shielded | Type | Toroidal |
| Size / Dimension | 0.495" L x 0.495" W (12.57mm x 12.57mm) | Series | LP |
| RoHS Status | Tray | Ratings | - |
| Polarization | Radial | Other Names | 553-1691 PE-53820NL-ND PE53820NL |
| Operating Temperature | -40°C ~ 130°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 12 Weeks |
| Manufacturer Part Number | PE-53820NL | Height - Seated (Max) | 0.375" (9.52mm) |
| Hardware Type | 115µH | Frequency - Test | - |
| Frequency - Self Resonant | 400 mOhm | Expanded Description | 115µH Shielded Toroidal Inductor 670mA 400 mOhm Radial |
| ESR (Equivalent Series Resistance) | ±20% | Diameter - Shoulder | - |
| Description | FIXED IND 115UH 670MA 400 MOHM | DC Resistance (DCR) | - |
| Current Rating | 670mA | Current - Saturation | - |
