PE-53682NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PE-53682NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PE-53682NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PE-53682NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | FIXED IND 4.7UH 10.4A 8.3 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1225 pcs | ||||
|---|---|---|---|---|---|
| $0.502 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PE-53682NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | FIXED IND 4.7UH 10.4A 8.3 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76244 pcs | Data sheet | Toroid-SLIC Series Datasheet |
| Category | Inductors, Coils, Chokes | Type | Toroidal |
| Tolerance | - | Supplier Device Package | - |
| Size / Dimension | 0.740" L x 0.740" W (18.80mm x 18.80mm) | Shielding | Unshielded |
| Series | SLIC | Ratings | - |
| Q @ Freq | - | Packaging | Tube |
| Package / Case | Nonstandard | Other Names | PE53682NL |
| Operating Temperature | -40°C ~ 130°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 4.7µH | Height - Seated (Max) | 0.390" (9.91mm) |
| Frequency - Self Resonant | - | Features | - |
| Detailed Description | 4.7µH Unshielded Toroidal Inductor 10.4A 8.3 mOhm Max Nonstandard | DC Resistance (DCR) | 8.3 mOhm Max |
| Current Rating | 10.4A | Current - Saturation | - |
