PA3655NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PA3655NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PA3655NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PA3655NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | CURR SENSE XFMR 34A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | 80 pcs |
|---|---|---|---|---|---|
| $1.327 | $1.171 | $1.034 | $0.839 | $0.741 | |
| 160 pcs | 560 pcs | 1040 pcs | 5040 pcs | ||
| $0.722 | $0.605 | $0.566 | $0.527 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PA3655NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | CURR SENSE XFMR 34A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 56714 pcs | Data sheet | PA3655NL |
| Category | Transformers | Type | Invasive |
| Turns Ratio - Primary:Secondary | - | Termination Style | PC Pin |
| Size / Dimension | 0.810" L x 0.580" W (20.57mm x 14.73mm) | Series | - |
| Ratings | - | Packaging | Tray |
| Other Names | 553-2173 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 76mH |
| Height - Seated (Max) | 0.750" (19.05mm) | Frequency Range | 50kHz ~ 500kHz |
| Energy Time (E.T.) | - | Detailed Description | 34A Current Sense Transformer 50kHz ~ 500kHz 15.8 Ohm Primary, 1.7 mOhm Secondary 76mH Through Hole |
| DC Resistance (DCR) | 15.8 Ohm Primary, 1.7 mOhm Secondary | Current Ratio | 200:200:1 |
| Current Rating | 34A |
