P1597NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy P1597NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy P1597NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | P1597NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | XFRMR FOR LINEAR TECH CHIPSET |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 80 pcs | 160 pcs |
|---|---|---|---|---|---|
| $1.111 | $0.899 | $0.726 | $0.681 | $0.65 | |
| 320 pcs | 560 pcs | 1040 pcs | 5040 pcs | ||
| $0.631 | $0.612 | $0.593 | $0.545 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | P1597NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | XFRMR FOR LINEAR TECH CHIPSET | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 61132 pcs | Data sheet | P1597(NL) SMT Pwr Xfrmr |
| Category | Transformers | Voltage - Primary | - |
| Voltage - Isolation | 2000Vrms | Voltage - Auxiliary | - |
| Type | For DC/DC Converters | Size / Dimension | 0.453" L x 0.339" W (11.50mm x 8.60mm) |
| Series | - | Packaging | Tube |
| Other Names | 553-1632-5 P1597NL-ND |
Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Intended Chipset | LTC1535 | Inductance @ Frequency | - |
| Height - Seated (Max) | 0.354" (9.00mm) | Frequency | - |
| Footprint | 0.453" L x 0.512" W (11.50mm x 13.00mm) | Chipset Manufacturer | Linear Technology |
| Applications | Isolation |
