P0401NLT
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy P0401NLT with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy P0401NLT with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | P0401NLT |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | INDUCT ARRAY 2 COIL 27.4UH SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1500 pcs | ||||
|---|---|---|---|---|---|
| $0.492 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | P0401NLT | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | INDUCT ARRAY 2 COIL 27.4UH SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 69742 pcs | Data sheet | P0yyyNL Tomcat Series |
| Category | Inductors, Coils, Chokes | Tolerance | ±20% |
| Size / Dimension | 0.715" L x 0.590" W (18.16mm x 14.99mm) | Shielding | Unshielded |
| Series | Tomcat | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | Nonstandard |
| Operating Temperature | -40°C ~ 130°C | Number of Coils | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance - Connected In Series | 109.8µH | Inductance - Connected In Parallel | 27.4µH |
| Height | 0.310" (7.87mm) | Detailed Description | Unshielded 2 Coil Inductor Array 109.8µH Inductance - Connected in Series 27.4µH Inductance - Connected in Parallel 38.15 mOhm DC Resistance (DCR) - Parallel 4.4A Nonstandard |
| DC Resistance (DCR) - Series | 152.6 mOhm | DC Resistance (DCR) - Parallel | 38.15 mOhm |
| Current Rating - Series | 2.2A | Current Rating - Parallel | 4.4A |
