HM1190NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HM1190NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HM1190NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HM1190NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | MDL,SIN,100D,1:1,SMT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 40 pcs | 80 pcs | |
|---|---|---|---|---|---|
| $1.591 | $1.29 | $1.043 | $0.977 | ||
| 120 pcs | 280 pcs | 520 pcs | 1000 pcs | ||
| $0.933 | $0.906 | $0.878 | $0.851 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HM1190NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | MDL,SIN,100D,1:1,SMT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 39810 pcs | Data sheet | HM1190NL Datasheet |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1CT:1CT Transmitter, 1CT:1CT Receiver | Transformer Type | LAN 10/100 Base-T |
| Size / Dimension | 0.500" L x 0.358" W (12.70mm x 9.09mm) | Series | - |
| Other Names | 1840-1177 HM1190NL-ND |
Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 21 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 350µH | Height - Seated (Max) | 0.236" (5.99mm) |
| Energy Time (E.T.) | - |
