HD8006FNL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HD8006FNL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HD8006FNL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HD8006FNL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | TRANSFORMER HDBASET 140W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 35 pcs | 70 pcs | |
|---|---|---|---|---|---|
| $3.359 | $2.612 | $2.541 | $2.188 | ||
| 105 pcs | 280 pcs | 525 pcs | 1015 pcs | ||
| $2.089 | $2.047 | $2.012 | $1.976 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HD8006FNL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | TRANSFORMER HDBASET 140W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 18962 pcs | Data sheet | HDBaseT Modules Product InfoHD8006FNL Drawing Spec |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1:1 | Transformer Type | HDBase-T |
| Size / Dimension | 0.698" L x 0.625" W (17.73mm x 15.88mm) | Series | - |
| Other Names | 1840-1179-5 | Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 120µH | Height - Seated (Max) | 0.320" (8.12mm) |
| Energy Time (E.T.) | - |
