CX2156NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CX2156NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CX2156NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CX2156NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | BALUN 2.3MHZ-2.7GHZ 1:1 5SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.058 | $0.857 | $0.693 | $0.649 | $0.62 | |
| 300 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.602 | $0.584 | $0.565 | $0.52 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CX2156NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | BALUN 2.3MHZ-2.7GHZ 1:1 5SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 66953 pcs | Data sheet | CX2156NL/CX2078NL/CX2081NL RF Transformer |
| Category | RF/IF and RFID | Series | - |
| Return Loss (Min) | - | Phase Difference | - |
| Packaging | Tray | Package / Case | 5-SMD |
| Other Names | 553-1499 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss (Max) | 0.2dB |
| Impedance - Unbalanced/Balanced | 1:1 | Frequency Range | 2.3MHz ~ 2.7GHz |
| Detailed Description | RF Balun 2.3MHz ~ 2.7GHz 1:1 5-SMD |
